LabCore Materials
CR2025 Coin Cell Case Sets
CR2025 Coin Cell Case Sets (100 Sets), 304 Stainless Steel with Funnel Springs (15.4x1.1mm) and Spacers (15.8x0.5mm), Anti-Static Packaging

CR2025 coin cell hardware kit, high-purity 304 stainless steel (SS304, austenitic, non-ferromagnetic), standard CR2025 dimensions (Ø20mm × 2.5mm height). Each set includes positive cap, negative cap, funnel-shaped spring (OD15.4mm × 1.1mm thick), and spacer (OD15.8mm × 0.5mm thick); 100 sets per pack. Components are multi-stage ultrasonically cleaned (DI water + anhydrous ethanol), oven-dried, and glovebox-ready—no pre-treatment required. Spring provides uniform contact pressure; spacer optimized for standard electrode stack thickness. Compatible with EC, DMC, EMC, PC and other common Li/Na organic electrolyte systems. For Li-ion half-cell/full-cell, Na-ion battery, and solid-state battery prototype assembly and electrochemical cycling tests.
Order / Quote
| Model | Pack | Price | Action |
|---|---|---|---|
| CR2025-100In stock · Amazon | CR2025-100 PACK100 sets per pack (cap + case + spring + spacer) | $49.00 | Buy on Amazon 1000+ units: request wholesale pricing → |
Specifications
| Parameter | Value | Unit |
|---|---|---|
| Material | 304 stainless steel (SS304, non-ferromagnetic) | |
| Cell format | CR2025 (Ø20 × 2.5) | mm |
| Set contents | Cap + case + spring + spacer | |
| Spring | OD15.4 × 1.1 thick | mm |
| Spacer | OD15.8 × 0.5 thick | mm |
| Pack size | 100 | sets/pack |
| Surface treatment | Ultrasonic cleaned (DI water + ethanol), oven-dried, glovebox-ready |
Setup & Troubleshooting
- How Much Electrolyte Goes in a CR2032?A dosing range for every purpose — screening, rate tests, long cycling, sulfides — how to calculate it from E/C ratio, and the failure symptoms that tell you the volume was wrong before the data is.
- CR2032 Coin Cell Assembly Guide for Research LabsA complete guide to assembling research-grade CR2032 coin cells: component functions, correct stack order, crimping technique, and how to diagnose common failure modes.
Compare & Choose
- CR2032 vs CR2025 vs CR2016: What Are the Differences?Same 20 mm diameter, same lithium–manganese dioxide chemistry — the three formats differ only in height, and capacity, weight and hardware compatibility follow that one dimension. Parameter comparison, the physics behind the capacity numbers, and how the difference plays out in laboratory coin cell hardware.
- CR2032 vs CR2025 vs CR2016: Which Coin Cell Size for Your Battery Research?A complete comparison of CR2032, CR2025, and CR2016 coin cell sizes for research applications: dimensional specs, capacity differences, impedance characteristics, and how to choose the right size for your electrochemical testing.
- 304 vs 316 Stainless Steel Coin Cell Cases: Material Selection GuideComprehensive comparison of 304 vs 316 stainless steel for CR2032 coin cell cases, analyzing corrosion resistance, cost, and electrochemical performance to guide material selection in lithium-ion battery research.
Product Images

Shipping & Compliance
- Non-Amazon orders ship from our Shenzhen facility via DHL / FedEx — typically 5–10 business days in transit to the US and EU, with tracking. Bulk orders may go by air freight.
