Staggered Herringbone Micromixer Chip, PDMS/Glass, Chaotic-Advection Mixing, Plasma-Bonded, for Nanoparticle & LNP Synthesis Research, with Tubing Kit, 45x20mm (RUO)
Staggered herringbone micromixer (SHM) with 21 µm-deep grooves driving chaotic advection. >90% mixing in a single channel length. For nanoparticle synthesis, LNP formulation research and protein crystallization screening (RUO).
The Staggered Herringbone Micromixer (SHM) integrates 21 µm-deep × 40 µm-wide herringbone grooves into a 200 µm-wide × 79 µm-deep main channel, driving chaotic advection that achieves >90% mixing efficiency within a single channel length. RTV615 PDMS is permanently plasma-bonded to borosilicate glass, withstanding sustained flow pressure with zero leakage. The complete mixing kit includes PTFE tubing, blunt needles and a syringe; 0.7 mm inlet/outlet ports connect to standard fittings. Compact 45×20 mm body fits common chip holders. Ideal for nanoparticle synthesis, lipid nanoparticle (LNP) formulation research, liposome preparation and protein-crystallization screening. **For research use only (RUO). Not for use in diagnostic or therapeutic procedures.**
In stock at Amazon warehouse, ship same day: [https://www.amazon.com/dp/B0H6F3FL2R](https://www.amazon.com/dp/B0H6F3FL2R)
Order / Quote
| Model | Pack | Price | Action |
|---|---|---|---|
| LC-SHM-M0004-1In stock | Staggered Herringbone Micromixer, 200×79 µm Main Channel, 45×20 mm, with Tubing Kit1× PDMS/glass chip (45×20 mm), 1× PTFE tubing set, 2× blunt needle tips, 1× syringe, 1× sealed ESD bag with RUO label | As listed on Amazon | 10+ units: request wholesale pricing → |
Specifications
| Parameter | Value | Unit |
|---|---|---|
| Material | RTV615 PDMS / Borosilicate Glass | |
| Mixer Geometry | Staggered Herringbone (SHM) | |
| Main Channel Width | 200 | µm |
| Main Channel Depth | 80 | µm |
| Groove Depth | 40 | µm |
| Chip Format | 45 × 20 | mm |
| Substrate Thickness | 1 | mm |
| Port Size | 0.7 (22-gauge compatible) | mm |
| Bonding | Oxygen Plasma (Permanent) | |
| Operating Pressure | ≤ 0.4 | MPa |
Product Images
Shipping & Compliance
- Ships as empty microfluidic hardware. No reagents, no biological materials. Not classified as dangerous goods.
